24 Volt 200 Watt Electric Scooter Motor 24V 200W 2750 RPM electric scooter motor. Powerful four brush permanent magnet design with 100% ball bearing construction. Includes 13 tooth drive belt cog for 5mm pitch drive belts. 17" long power leads. The shaft rotation is reversible by reversing power leads. Dimensions: 4" wide x 3-1/4" long excluding shaft, 4-1/4" long including shaft. Mounting bracket measures 4-3/8" x 2-1/4" with 4 threaded mounting holes. Weight 3.85 lbs. Made by Unite®.Cross...

24 Volt 250 Watt Electric Scooter Motor 24V 250W 2650 RPM electric scooter motor. Powerful four brush permanent magnet design with 100% ball bearing construction. Includes 13 tooth drive belt cog for 5mm pitch drive belts. 12" long power leads with 1/4" push-in connectors. Shaft rotation reversible by reversing power leads. Dimensions: 4" wide x 3-1/4" long excluding shaft, 4-1/4" long including shaft. Mounting bracket measures 4-1/2" x 2-1/8 with 4 threaded mounting holes. Weight 4.3 lbs....

24 Volt 250 Watt Electric Bicycle Gear Motor 24V 250W electric bicycle motor with built-in gear reduction transmission. Output shaft speed 400 RPM. Includes 9 tooth sprocket for 1/2" x 1/8" bicycle chain. Different size fixed and freewheel sprockets are available for this motor. Output shaft is 11mm OD with a 4mm wide x 2mm deep keyway. Powerful four brush permanent magnet design. 100% ball bearing construction. 24" long power leads. Shaft rotation reversible by reversing power leads. Three...

24 Volt 250 Watt 2650RPM Electric Scooter Motor Powerful four brush permanent magnet design with 100% ball bearing construction. Includes 11 tooth sprocket for #25 chain. Compatible with sprockets that have a 7.1mm x 8.1mm ID D-Bore.15" long power leads with 1/4" push-in connectors. Shaft rotation reversible by reversing power leads. Dimensions: 4" wide x 3-1/4" long excluding shaft, 4-1/4" long including shaft. Mounting bracket measures 4-1/4" x 2-1/8 with 4 threaded mounting holes. Weight...

24 Volt 350 Watt Gear Motor Output shaft speed: 300 RPM. Includes 9-tooth sprocket for #410 (1/2" x 1/8") bicycle chain. Different size and freewheel sprockets are available for this motor. Powerful four-brush permanent magnet design. 100% ball bearing construction. 22" long power leads. Mounting bracket dimensions: 4-3/8" long x 2-3/16" wide. Motor dimensions: 4-1/8" outside diameter x 4-5/8" long excluding transmission and output shaft, 5-3/8" long including transmission and output shaft....

24 Volt 350 Watt Electric Scooter Motor 24 Volts350 Watts2800 RPMPowerful four brush permanent magnet design with 100% ball bearing construction.18" long power leads. 11 tooth sprocket for #25 chain with 10mm x 8mm D-bore.Shaft rotation reversible by reversing power leads.Mounting bracket measures 4-1/4" x 2-1/8" with 4 threaded mounting holes.Dimensions: 4"(H) x 4"(W) x 5-1/2"(L).Weight 5.2 lbs Cross references motor number: MY1016 Dimensions: PDF Compatibility: Some Chinese-made...

24 Volt 450 Watt Electric Bicycle Gear Motor 24V 450W electric bicycle motor with built-in gear reduction transmission. Output shaft speed 420 RPM. Includes 9 tooth sprocket for 1/2" x 1/8" bicycle chain. Different size fixed and freewheel sprockets are available for this motor.Output shaft is 11mm OD with a 4mm wide x 2mm deep keyway. Powerful four brush permanent magnet design. 100% ball bearing construction. 24" long power leads. Shaft rotation reversible by reversing power leads. Three...

24 Volt 450 Watt Planetary Gear Motor with Cooling Fan 24V 450W electric bicycle, tricycle, and go-kart motor with built-in planetary gear reduction transmission and cooling fan. Output shaft speed 560 RPM. Shaft diameter where sprocket seats into is 12mm x 17mm with a dual D-bore. Includes 10 tooth sprocket for #41 and #420 chain (both of these chain sizes work with this motor's sprocket).Different size sprockets are available for this motor. Powerful four brush permanent magnet design with...

24 Volt 450 Watt Gear Motor 24 Volts DC. 450 Watts. 24 Amps. Output shaft speed 450 RPM. Includes 10 tooth sprocket for #41 and #420 chain (both of these chain sizes work with this motor's sprocket). Different size sprockets are available for this motor. Powerful four brush permanent magnet motor design with 100% ball bearing construction. Heat-treated hardened steel spur gear transmission. 24" long 12 AWG power leads. Shaft rotation is reversible by reversing power leads. Mounting bracket...

24 Volt 500 Watt 2500 RPM Electric Scooter Motor 24V 500W 2500 RPM electric scooter motor. Powerful four brush permanent magnet design with 100% ball bearing construction. Includes 11 tooth sprocket for #25 chain. 8.5mm x 10mm sprocket mounting area. Different size sprockets are available for this motor18" long power leads. Shaft rotation reversible by reversing power leads.Dimensions: 4-1/4" wide x 5-1/2" long excluding shaft, 6-1/2" long including shaft. Shaft is 1" long and sprocket is...

24 Volt 500 Watt 2500 RPM Electric Scooter Motor 24V 500W 2500 RPM electric scooter motor. Powerful four brush permanent magnet design with 100% ball bearing construction. Includes 11 tooth sprocket for #25 chain. 8.5mm x 10mm sprocket mounting area. Sprocket is spaced 11mm away from face plateDifferent size sprockets are available for this motor.18" long power leads. Shaft rotation reversible by reversing power leads. Shaft is 1" long and sprocket is spaced 5/8" away from front of motor....

24 Volt 600 Watt 2600RPM Currie Electric Scooter Motor With 15 Tooth Freewheeling Sprocket (MOT-24600)
