Throttle to controller wire length 60"Battery pack to controller wire length 18"Motor to controller wire length 18"Charger port wire length 20" The power switch is on the throttle which makes turning the power on and off much easier than if using the original battery box mounted power switch. The throttle has battery indicator lights which light up when the power is on. The chain with master link in this kit is oversized and will need to be shortened to the correct length after the motor is...

Toggle Switch to Controller wire length 48"Throttle to Controller wire length 48"Battery Pack to Controller wire length 24"Charger Port to Controller wire length 24"Motor to Controller wire length 18" The toggle switch has 48" of wire so it can be mounted on the front of the go kart if wanted. This wire length can be shortened on request. The chain with master link in this kit is oversized and will need to be shortened to the correct length after the motor is installed. This is a modification...

Toggle switches to controller wire length 59"Throttle to controller wire length 59"Voltmeter to controller wire length 59"Battery pack to controller wire length 24"Charger port wire length 20"Controller to reverse relay wire length 12"Motor to reverse relay wire length 18" The toggle switches and Voltmeter have 59" of wire so they can be mounted in the front of the Dune Buggy if wanted. This wire length can be changed on request. The chain with master link in this kit is oversized and will...

Toggle Switches to Controller wire length 48" Throttle to Controller wire length 48" Battery Pack to Controller wire length 24" Charger Port to Controller wire length 24" Controller to Reverse Relay wire length 12" Motor to Reverse Relay wire length 18" The toggle switches have 48" of wire so it can be mounted on the front of the go kart if wanted. This wire length can be shortened on request. The chain with master link in this kit is oversized and will need to be shortened to the correct...

Toggle Switches to Controller wire length 48"Throttle to Controller wire length 48"Battery Pack to Controller wire length 24"Charger Port to Controller wire length 24"Controller to Reverse Relay wire length 12"Motor to Reverse Relay wire length 18" The toggle switches have 48" of wire so it can be mounted on the front of the go kart if wanted. This wire length can be shortened on request. The master link in this kit is oversized and will need to be shortened to the correct length after the...

36 Volt 1000 Watt SPD-CT660B9 Controller and THR-68 Throttle Kit We install a connector on the throttle that plugs into the controller so everything is properly wired and works together.

36 Volt 1000 Watt SPD-CT660B9 Controller and THR-86 Throttle Kit We install a connector on the throttle that plugs into the controller so everything is properly wired and works together.

36V 1000W Electric Scooter and Bike Speed Controller Designed for 36 Volt motors up to 1000 Watts.Maximum current 32 Amps.Under Voltage protection 31 Volts.Current limiting feature helps prevent controller and motor damage due to over-current conditions. Under voltage protection feature prevents over-discharge of the battery pack and extends battery life.Uses standard 3-wire variable speed hall-effect throttle. Wiring Directions Plug-and-Play Compatible Throttles: THR-86-C1 36 Volt Half Twist...

36 Volt 1000 Watt Throttle, Controller, Battery Pack Wiring Harness, and Charger Port Kit All parts will have matching and labeled connectors on then for easy plug-and-play installation. Includes all necessary electrical parts except for the batteries, motor, and battery charger. The red push button switch on the throttle is the on/off power switch. The throttle has a battery level indicator which lights up when the power switch is on. ...

36 Volt 10Ah LiFePO4 Battery Dimensions: 8.3 x 5.2 x 3.1 inchesOutput Terminal: Anderson Powerpole PP45Charger Port: Coaxial (5.5mm x 2.1mm)Weight: 7.6 poundsNominal Voltage: 36 VoltsOpen Circuit Voltage Range: 30 to 38.4 VoltsCapacity: 10Ah (10 Amp hour)Maximum Continuous Discharge Current: 10 AmpsMaximum Peak Discharge Current: 20 Amps (5 Seconds)Maximum Continuous Discharge Power: 360 WattsCharging Voltage: 43.8 VoltsMax. Battery Charger Current: 2 AmpsDischarge/Recharge Cycle Life: 2000+...

36 Volt 150 Amp Motor Reversing Contactor 36 Volts (36V) DC 150 Amp (150A) Contacts Coil power consumption 8 Watts. Has no-load rated make or break contacts so it needs to be used with a speed controller and the vehicle should be stopped before switching between forward, park, and reverse directions. Applies electronic braking to the motor when the switch is in the park position which helps prevent damage to the controller in the event of accidentally switching directions when the vehicle is...

36 Volt 150 Amp Power Contactor 36V DC 150A continuous duty SPST power contactor. Normally open contacts rated at 150 Amps continuous duty. Coil power consumption 8 Watts. Two 6mm contacts mounting posts work with 1/4" ring terminals and two 4mm coil mounting posts work with #8 ring terminals. Mounting posts include flat washers, lock washers, and nuts. 2-7/16" wide steel mounting plate on back of solenoid with two 6mm (1/4") diameter mounting holes spaced 1-13/16" apart from center to center....
